A Case of Central Nervous System Metastasis of Anaplastic Lymphoma Kinase Positive Anaplastic Large Cell Lymphoma Manifested as Central Nervous System Vasculitis

Hongjuan Wang, Xiaowei Xu and Lanjuan Li^*
*Correspondence: Lanjuan Li, State Key Laboratory for Diagnosis and Treatment of Infectious Diseases, National Clinical Research Center for Infectious Diseases, Collaborative Innovation Center for Diagnosis and Treatment of Infectious Diseases, The First Affiliated Hospital, Zhejiang University School of Medicine, Hangzhou, P.R. China, Email:

Keywords

Anaplastic large cell lymphoma • Anaplastic lymphoma kinase • Central nervous system metastasis • Central nervous system vasculitis

Introduction

Anaplastic Large Cell Lymphoma (ALCL) is a rare distinct subset of T-cell non-Hodgkin lymphomas (T-cell NHL). The CD30 antigen expressing large cell lymphoma was first described in 1985 by Stein [1]. Anaplastic Lymphoma Kinase (ALK), which induces neoplastic transformation is the tumor cell product of a fused gene that comes from a chromosomal translocation t (2; 5) (p23;q35) on chromosome or a rearrangement of the ALK gene with various partner genes [2-6]. In The World Health Organization (WHO) classification of tumors of the hematopoietic and lymphoid tissues, ALCL is grouped into three distinct clinical sub-entities, the primary cutaneous ALCL, the primary systemic ALK + ALCL and the primary systemic ALK-ALCL, according to organ distribution and the expression of ALK [7]. As is well known, ALK + ALCL patients are generally associated with younger age and have a better prognosis with overall survival of 71%-83% [8,9]. Besides the vast majority of ALCL present as nodal disease, ALCL can also involve in skin (21%), bone (17%) and soft tissues (17%) [9]. Compared with B-cell non-Hodgkin lymphomas, T-cell NHL involving Central Nervous System (CNS) is much rare. T-cell NHL account for less than 4% of the primary involvement in the CNS NHL [10,11]. ALCL is an even rarer variant of T-cell lymphoma primary involving the CNS, most of which is associated with meningeal lesions [12]. Vasculitis can be secondary to lymphoma or the treatment. Some lymphoma can even present as vasculitis [13]. Vessel injury may occur as a direct result of infiltrating neoplastic cells [14]. However, there were rare reports about lymphoma and CNS vasculitis. Furthermore, no report about ALK + ALCL and CNS vasculitis. In the present report, we first describe a case of ALK + ALCL metastasized to the CNS in a 17-year-old teenage who presented as CNS vasculitis in the beginning. We also reviewed the literature on ALK + ALCL occurring in the CNS and relevance with CNS vasculitis.

Case Report

In January, 2020, a 17-year-old boy presented with persistent fever accompanied with diffuse maculopapular rashes and mild chest pain. When the patient was admitted to the Department of Infection of the First Affiliated Hospital, Zhejiang University School of Medicine, a mass was found in the left clavicle area of the neck. The mass turned out to be enlarged Lymph nodes by ultrasound and Computerized Tomography (CT). Positron Emission Tomography-Computed Tomography (PET-CT) showed that there were multiple enlarged lymph nodes in the left clavicle area, the entrance of the left thoracic cavity, the left anterior superior mediastinum, and the posterior margin of the left sternum. The lesions in the left clavicle area were fused into a mass and the Fluorodeoxyglucose (FDG) metabolism was significantly increased. Multiple small lymph nodes in the left parapharyngeal space, the left lower neck, and the lower margin of the left parotid gland had slight metabolic increase. Lesions with increased FDG metabolism were also found in skin, subcutaneous nodules, bone, left kidney and lung. While no abnormal increase of FDG metabolism was found in CNS. Lymph node biopsy was conducted. Immunohistochemistry studies showed CD3 (partly + ), CD20 (-), Ki-67 (+, 40%), CD30 (+), CD5 (-), CD10 (-), Bcl-2 (-), Bcl-6 (+, 25%), MUM1 (+, 20%), PAX-5 (-), CD21 (-), Cyclin D1 (-), c-Myc (+, 12%), ALK (+), EBER (-), CD23 (-), CD2 (partly +), CD4 (+), CD7 (+), CD8 (-), CD56 (-), TIA-1 (+), TDT (-), MPO (-), CK (pan) (-), CD34 (-), CD117 (-). Thus, a diagnosis of ALK + ALCL was made. The patient was referred to the hematology department and underwent six courses of systemic chemotherapy of CHOP (cyclophosphamide, doxorubicin, vincristine, and dexamethasone). The original symptoms were relieved. Repeated imaging of the neck showed significant reduction of the lymph nodes.

In May, 2020, about 1 week after the sixth cycle of chemotherapy, the patient developed symptoms of fever, headache and a short convulsion with unconsciousness. He was admitted to the Department of Infection. When he was admitted, the pathologic signs of nervous system examination were negative. Initial laboratory evaluation showed that blood routine examination had no obvious abnormality, erythrocyte sedimentation rate was 16 mm/1 h and C-reactive protein was slightly elevated (10.5 mg/L). Lactate dehydrogenase was 306 U/L and ferritin was 1099.6 ng/mL. Blood culture was free of bacteria. The DNA of Epstein-Barr virus and Cytomegalovirus was negative. Antinuclear antibodies and antineutrophil cytoplasmic antibody were negative. The cranial CT showed no lesions. Lumbar puncture was performed; the pressure was 250 mm H₂O. Cerebrospinal Fluid (CSF) examination showed 25 μl nucleated cells. The CSF glucose, chlorine and protein were in normal range. And CSF adenosine deaminase, lactate dehydrogenase was normal. The Flow cytometry detection of CSF showed no atypical lymphocytes. High-throughput sequencing of DNA and RNA sequences in CSF did not find bacteria, fungi, viruses, parasites, mycoplasma, chlamydia or mycobacterium. Antibiotic therapy was ineffective. So, we excluded infection. The Color Doppler sonography of vessels demonstrated severe stenosis in the M1 segment of the right middle cerebral artery and the terminal segment of the right internal carotid artery, mild stenosis of Basilar artery and moderate stenosis of left anterior cerebral artery (Figure 1). No stenosis was found in peripheral Vessels. The severe stenosis of CNS arteries suggested CNS vasculitis. During the patient's hospitalization, the patient had persistent fever accompanied with headache, dizziness and palpitations. And he also underwent epileptic seizures and developed the symptoms of paroxysmal slurred speech, slight deviation of mouth, numbness and weakness of left upper limb. We gave priority to CNS vasculitis and treat the patient with methylprednisolone, and all the symptoms were relieved.

However, the cranial MR showed lesions in right parietal temporal cortex (Figure 2). We conducted another PET-CT, and it showed FDG metabolism in the right parietal lobe, right frontal lobe and left temporal lobe was higher than contralateral (Figure 3). Compared with the previous PET-CT, the original enlarged lymph nodes were significantly reduced and partially disappeared, FDG metabolism was significantly reduced, and the original skin and subcutaneous nodules, bone, left kidney and lung lesions were not found this time. According to the presence of cranial nerve palsy and the demonstration of lesions on MRI as well as PET-CT, we considered CNS metastasis of ALCL. The patient was discharged from the First Affiliated Hospital, Zhejiang University School of Medicine and got admitted to Huashan Hospital affiliated to Fudan University. Their Flow cytometry detection of CSF showed a nucleated cell count of 18 μl, small lymphocytes accounting for about 40% (CD3 + 84.9% CD4 + 37.6% CD 8 + 41.4%). Atypical large lymphocytes accounted for 20.1%, expressing positive markers (CD45 + cyCD3 + CD7 + CD4 + CD30 + 52.9%) and negative markers (CD2- CD3- CD5- CD8- CD10- CD1a- TdT-). Cellular morphology of CSF showed that clusters of atypical lymphocytes were visible. They had large, round or irregular shapes, a large amount of cytoplasm, irregular 1-3 nucleoli, purplish red granules, multiple vacuoles in the cytoplasm and most of them have pseudopodia. Therefore, CNS metastasis of ALCL was diagnosed. No brain autopsy was performed.

Discussion

CNS metastasis in T-cell NHL is rare and has a dismal prognosis [15]. In adult peripheral T-cell NHL patients, the reported median time to CNS involvement was 3.44 to 6.05 months and median overall survival time from relapse or progression to CNS was disappointed, which ranged from 1.1 to 2.63 months [15-18]. Extranodal involvement >1 site, International Prognostic Index (IPI) ≥ 3, skin and gastrointestinal involvement, elevated LDH level and involvement of the paranasal sinus were reported to be risk factors [15-18]. Among all the risk factors, Extranodal involvement >1 site was reported in multiple analyses [15-18]. ALCL seemed to have high proportion of T-cell NHL involving CNS [17]. A retrospective analysis showed that of a total of 74 peripheral ALK + ALCL patients, the 5-year cumulative incidence of CNS relapse was 5.4%, higher than ALK-ALCL or any other types of peripheral T-cell lymphoma. In addition, ALK + ALCL patients who had extranodal involvement >1 had very high risk of CNS relapse, whose one-year cumulative incidence was 17% and they all occurred within six months after diagnosis. Thus, evaluation of CNS involvement at the time of diagnosis was necessary and possible CNS-directed prophylaxis shall be considered [18]. A report about neuro-meningeal relapse in a large population of ALK + ALCL children in Europe showed that CNS involvement at first or subsequent relapse was reported in 26/618 patients. Median interval between initial diagnosis and first CNS involvement was 8 months. The 5-year cumulative risk of CNS involvement was 4%. Peripheral blasts, bone marrow involvement, and CNS involvement at diagnosis were reported to be high risk factors. The median survival after relapse to CNS was 23.7 months, and three-year overall survival after CNS relapse was 48.70%, which seemed to have a better prognosis than peripheral T-cell NHL in adult patients [19]. In addition, it was recommend that intensified CNS prophylaxis based on a last-generation ALK-inhibitor should be evaluated as part of front-line treatment in patients with high risk factors, while patients with no risk factors could undergo chemotherapy with minimal CNS prophylaxis [19]. Patient in this case had risk factors including >1 extra nodal site, IPI ≥ 3, elevated LDH level and skin involvement, without peripheral blasts, bone marrow involvement, or initial CNS involvement.

Vasculitis can occur secondary to lymphoma or the treatment. Intravascular lymphoma even presents as vasculitis [13]. A case of systemic ALK-ALCL associated with hypereosinophilia, granulomatous myositis and vasculitis was reported [20]. Another case reported that recurrent ALK-ALCL presenting as ulcerating skin lesions, and the biopsy revealed a necrotizing vasculitis which resulted from the infiltration of neoplastic cells [14]. However, there were rare reports about lymphoma and CNS vasculitis. Furthermore, no report about ALK + ALCL and CNS vasculitis. Carlo Salvarani found that lymphoma without involving the CNS can be diagnosed in the meantime with primary CNS vasculitis, which may suggest an immunologic paraneoplastic mechanism [21]. Pathology report confirmed that intravascular large B-cell lymphoma can present as CNS vasculitis [22]. A patient with Burkitt Lymphoma carrying a SH2D1A mutation developed fatal central nervous system vasculitis 6 months after completing treatment for lymphoma was reported [23]. Another case report described a patient diagnosed with primary CNS lymphoma developed severe leukocytoclastic vasculitis, which might due to high-dose methotrexate toxicity [24]. High-resolution vessel wall MRI appearance of biopsy-proven intravascular lymphoma can mimic CNS vasculitis [25]. Till now, there was no report about CHOP associated CNS vasculitis. As is well known, vasculitis is more associated with systemic leukemia. And researches confirmed that vessel injury can be a product of infiltration by neoplastic tumor cells instead of a paraneoplastic phenomenon mediated by benign inflammatory cells [14]. So, the CNS vasculitis in this patient might be caused by benign inflammatory cells mediated by ALK + ALCL, or resulted from the infiltration of ALK + ALCL, which could not be confirmed for the patient refused to conduct a brain biopsy.

Conclusion

We first present a case of a systemic ALK + ALCL patient who presented as CNS vasculitis but eventually it turned out to be CNS metastasis of ALK + ALCL. The CNS vasculitis might result from benign inflammatory cells mediated by ALK + ALCL, or ALK + ALCL might infiltrate CNS vessels. Therefore, when an ALK + ALCL patient had CNS symptoms while imaging revealed CNS vasculitis, we need to be vigilant that the patient may have CNS involvement.

References

1. Stein, Han. “The Expression of the Hodgkin's Disease Associated Antigen Ki-1 in Reactive and Neoplastic Lymphoid Tissue: Evidence that Reed-Sternberg Cells and Histiocytic Malignancies are Derived from Activated Lymphoid Cells.” Blood 66 (1985): 848-858.
2. Stein, Han. “CD30 ( + ) Anaplastic Large Cell Lymphoma: A Review of its Histopathologic, Genetic, and Clinical Features.” Blood 96 (2000): 3681-3695.
3. Christian Touriol, Catherine Greenland, Laurence Lamant and Karen Pulford, et al. “Further Demonstration of the Diversity of Chromosomal Changes Involving 2p23 in ALK-Positive Lymphoma: 2 Cases Expressing ALK Kinase Fused to CLTCL (Clathrin Chain Polypeptide-Like).” Blood 95 (2000): 3204-3207.
4. Sabattini, Ein. “WHO Classification of Tumours of Haematopoietic and Lymphoid Tissues in 2008: An Overview.” Pathol 102 (2010): 83-87.
5. Kaneko, Yamino. “A Novel Translocation, t (2;5) (p23;q35), in Childhood Phagocytic Large T-Cell Lymphoma Mimicking Malignant Histiocytosis.” Blood 73 (1989): 806-813.
6. Morris, Senba. “Fusion of a Kinase Gene, ALK, to a Nucleolar Protein Gene, NPM, in Non-Hodgkin's Lymphoma.” Sci 263 (1994): 1281-1284.
7. Vardiman, James. “The World Health Organization (WHO) Classification of Tumors of the Hematopoietic and Lymphoid Tissues: An Overview with Emphasis on the Myeloid Neoplasms.” Chem Biol Int 184 (2010): 16-20.
8. Reiter, Amit. “Successful Treatment Strategy for Ki-1 Anaplastic Large-Cell Lymphoma of Childhood: A Prospective Analysis of 62 Patients Enrolled in Three Consecutive Berlin-Frankfurt-Munster Group Studies.” J Clin Oncol 12 (1994): 899-908.
9. Falini, Bali. ALK + Lymphoma: Clinico-Pathological Findings and Outcome.” Blood 93 (1999): 2697-2706.
10. Mohamed Jiddane, François Nicoli, Pédro Diaz and Ulf Bergvall, et al. “Intracranial Malignant Lymphoma: Report of 30 Cases and Review of the Literature.” J Neurosurg 65 (1986): 592-599.
11. Faruk İldan, Hüseyin Bağdatoğlu, Bülent Boyar and Sebahattin Haciyakupoğlu, et al. “Combined Occurrence of Primary Cerebral Lymphoma and Meningioma.” Neurosurg Rev 18 (1995): 45-48.
12. Etsuco Fujisawa, Hidehiro Shibayama, Fumi Mitobe and Fumiaki Katada, et al. “A Case of Primary Central Nervous System Anaplastic Lymphoma Kinase Positive Anaplastic Large Cell Lymphoma Manifested as a Unilateral Pachymeningits.” Clin Neurol 57 (2017): 705-710.
13. Prayson, Richard. “Intravascular Lymphoma Mimicking Vasculitis.” J Clin Neurosci 34 (2016): 224-225.
14. Vinod E. Nambudiri, Amir Aboutalebi, Scott R. Granter and Arturo Saavedra. “Recurrent ALK-Negative Anaplastic Large T-Cell Lymphoma Presenting as Necrotizing Vasculitis.” Am J Dermatopathol 35 (2013): 512-516.
15. Fredrik Ellin, Jenny Landström, Mats Jerkeman and Thomas Relander. “Central Nervous System Relapse in Peripheral T-Cell Lymphomas: A Swedish Lymphoma Registry Study.” Blood 126 (2015): 36-41.
16. Ronit Gurion, Neha Mehta, Jocelyn C Migliacci and Andrew Zelenetz, et al. “Central Nervous System Involvement in T-Cell Lymphoma: A Single Center Experience.” Acta Oncol 55 (2015): 561-566.
17. Yi, James. “Elevated LDH and Paranasal Sinus Involvement are Risk Factors for Central Nervous System Involvement in Patients with Peripheral T-Cell Lymphoma.” Ann Oncol Euro Soc Med Oncol 22 (2011): 1636-1643.
18. Dai Chihara, Michelle A. Fanale, Roberto N. Miranda and Mansoor Noorani, et al. “The Risk of Central Nervous System Relapses in Patients with Peripheral T-Cell Lymphoma.” PloS One 13 (2018): 1461.
19. Giada Del Baldo, Rachid Abbas, Wilhelm Woessmann and Keizo Horibe, et al. “Neuro-Meningeal Relapse in Anaplastic Large-Cell Lymphoma: Incidence, Risk Factors and Prognosis: A Report from the European Intergroup for Childhood Non-Hodgkin Lymphoma.” British J Haematol 9 (2020): 01.
20. Penelope A. McKelvie, Shereen Oon, Evange Romas and Harshal Nandurkar, et al. “A Case of Systemic Anaplastic Lymphoma Kinase-Negative Anaplastic Large Cell Lymphoma Associated with Hypereosinophilia, Granulomatous Myositis and Vasculitis.” Leukemia Lymphoma 53 (2012): 2279-2282.
21. Carlo Salvarani, Robert D. Brown, Teresa J.H. Christianson and John Huston, et al. “Primary Central Nervous System Vasculitis Associated with Lymphoma.” Neurol 90 (2018): 847-855.
22. Corbin Rayfield, Lester Mertz, Katalin Kelemen and Fawad Aslam. “Vasculitis on Brain Angiography is Not Always Vasculitis: Intravascular Large B-Cell Lymphoma Mimicking Central Nervous System Vasculitis.” BMJ Case Rep 12 (2019): 8.
23. João Farela Neves, Lamberto Torralba Raga, Samuel C. C. Chiang and Bianca Tesi, et al. “Fatal Central Nervous System Lymphocytic Vasculitis after Treatment for Burkitt Lymphoma in a Patient with a SH2D1A Mutation.” Pediat Infect Dis J 38 (2019): 29-31.
24. Colette Hanna, Diego Villa, Carla Irani and Marwan Ghosn, et al. “Leukocytoclastic Vasculitis and Desensitization to High-dose Methotrexate in Primary Central Nervous System Lymphoma.” Clin Lymphoma, Myeloma Leukemia 18 (2018): 197-200.
25. Joanna D Schaafsma, Ferdinand Hui, Dolora Wisco and Susan M Staugaitis, et al. “High-Resolution Vessel Wall MRI: Appearance of Intravascular Lymphoma Mimics Central Nervous System Vasculitis.” Clin Neuroradiol 27 (2017): 105-108.
