Distal-type bronchiolar adenoma of the lung. Findings of intraoperative cytology and review of the literature

Keywords

Bronchiolar Adenoma • Distal-type • Cytology • Intraoperative Diagnosis

Abbreviations: BA: Bronchiolar adenoma • TTF-1: Thyroid transcription factor-1 • MUC: Mucin • CK: Cytokeratin • p16INK4a: Cyclin-dependent kinase inhibitor p16 • BRAFV600E: v-raf murine sarcoma viral oncogene homolog B1 • EGFR: E pidermal growth factor receptor • ALK-1: Anaplastic lymphoma kinase-1

Introduction

Bronchiolar adenoma (BA) is a recently recognized rare benign tumor of bronchiolar origin [1-3], and many pathologists and clinicians are unaware of this lesion. BA is often inappropriately diagnosed because it shows radiographic, gross, and histologic presentations similar to other localized lung disorders, especially to primary pulmonary adenocarcinoma. Improvement of diagnostic accuracy for BA is essentially important both for the surgical treatment and for judging the patient’s prognosis. BA reveals an indolent clinical course, as no recurrences or metastases have been reported in patients who underwent surgical resection. Hitherto, a total of 111 cases have been reported across the English, Japanese and Chinese literature, and the number is gradually increasing [1-14]. Recent molecular studies of BA discovered a high frequency of driver gene alterations, including mutations in the v-raf murine sarcoma viral oncogene homolog B1 (BRAFV600E), epidermal growth factor receptor (EGFR), ROS1 and Kirsten RAS(KRAS) and Harvey RAS genes, as well as anaplastic lymphoma kinase-1 (ALK-1) gene rearrangements [1-3,13]. We report herein a rare case of BA of distal type: We made an accurate diagnosis with intraoperative cytology and frozen section histology.

Case Presentation

Clinical summary

A 70-year-old Japanese male nonsmoker was hospitalized in Shimada General Medical Center, Shimada, Japan, because mediastinal and pulmonary lesions were pointed out during the check-ups for angina pectoris. Chest computed tomography scan revealed a 7.2 × 6.8 mm solid nodule without cavitation or pleural retraction at the peripheral area of the right lower lobe of the lung, as shown in Figure 1. A 12 × 12 mm-sized anterior mediastinal mass was also observed. No radiological and clinical features of interstitial lung disease were recognized. There was neither lymphadenopathy nor intrapulmonary metastasis. Primary lung cancer with thymoma was suspected preoperatively. The intraoperative frozen section diagnosis of the lung nodule was distal-type BA. Video-assisted thoracoscopic wedge resection of the lung tumor with excision of the mediastinal mass was performed (Figure 1). The mediastinal tumor was microscopically typical of thymoma, B1 type. The patient did not receive adjuvant therapy, and is currently doing well, four months after surgery.

Cytologic findings

Figure 1. Clinical imaging. (a) A chest computed tomography image reveals a 7.2 mm solitary, dense and solid nodule in the subpleural area of the right lower lung lobe (arrow). (b) The tumor agitated in red color is penetrated by large bronchiolo-arterial bundles (arrow).

In intraoperative touch smear cytology preparations of the lung nodule, ciliated columnal cells, mucous columnar cells and basal cells were observed. The background was mucinous but not necrotic. Neither nuclear pleomorphism nor mitosis was discerned. Immunocytochemistry was performed after applying a cell transfer method. The nuclei of the basal cells were immunoreactive for p40. Representative cytologic appearance including p40 positivity is illustrated in Figure 2.

Figure 2. Cytological findings (a-c: Papanicolaou, d: immunocytochemistry for p40). In touch cytology preparations, the background is mucinous (asterisk) and not necrotic (a) Numbers of ciliated columnal cells (b) and mucous cells can be identified (c) Cilia are indicated by arrows. Basal cells immunoreactive for p40 in the nuclei are dispersed (d) Nuclear pleomorphism is not discerned, and mitosis is hardly observed.

Gross findings

Grossly, the peripheral lung lesion displayed a well-circumscribed, 7 × 7 × 4 mm-sized, grayish tan-colored and gelatinous mass, as displayed in Figure 3. No pleural retraction was observed. The resected margins were negative.

Figure 3. Gross appearance of the wedge-resected lung tumor after formalin fixation. A well-circumscribed, grayish tan-colored, and gelatinous mass measuring 7 × 7 × 4 mm is located just beneath the pleura (arrow). No pleural retraction is seen.

Histological findings

At low-powered magnification, the neoplasm was an unencapsulated, well-demarcated nodule predominantly with glandular architectures, as shown in Figure 4a. Mucin was accumulated in both the tumor itself and adjacent alveolar spaces. By imaging analysis, unpaired, medium-sized muscular arteries entering the tumor were observed (Figure 1b), indicating peribronchiolar location. Columnar epithelial cells revealed lepidic growth, in association with mild lymphocytic infiltration in the stroma, and they contained cytoplasmic mucin, resembling gastric foveolar or glandular cells, as displayed in Figure 4b. The bronchiolar-like epithelial cells displayed a distinct two-layered structure, consisting of both luminal and basal layers. No papillary structures were noted. The tumor cells were devoid of nuclear atypia, mitosis, apoptosis, and necrosis. The luminal layer was composed of ciliated columnar cells and mucous cells, as illustrated in Figure 4c: the presence of a continuous layer of basal cells beneath the luminal layer represented the most pathognomonic finding. Immunohistochemically, the ciliated, mucous and basal cells expressed cytokeratin (CK) 7 and cyclin-dependent kinase inhibitor p16 (p16INK4a) (clone G175-405). Thyroid transcription factor-1 (TTF-1: clone 8G7G3/1) and napsinA were positive in the luminal-sided ciliated and mucous columnar cells. CK5/6, p40, p63, and podoplanin (clone D2-40) clearly demonstrated the basal cells. Mucin 5AC (MUC5AC) was focally expressed in the apical cytoplasm of the mucous cells. Ki-67 labeling index was 3%. Negative immunohistochemical markers included CK20, carcinoembryonic antigen, HER2/neu, MUC2, and MUC6. Figure 5 illustrates representative immunohistochemical findings.

Figure 4. Histological findings (a–c: hematoxylin and eosin staining; a: low-power, b: intermediate-power, c: high-power). (a)The subpleural lung parenchyma is occupied by a defined nodular and mucin-filled lesion. (b) The growing bronchiolar epithelia are associated with mild lymphocytic infiltration in the stroma. Mucin production is observed in the cytoplasm. (c) A high-powered view reveals a two-layered pattern of growth: basal cells are consistently distributed beneath the luminal cells. Arrow indicates ciliated cells.

Figure 5. Immunohistochemical findings of the lung tumor. (a) CK7; (b) TTF-1; (c) p16INK4a; (d) MUC5AC; (e) p40 and (f) CK5/6. CK7 and p16INK4a are expressed in both the luminal and basal cells. TTF-1 is immunoreactive in the nuclei of luminal-sided cells. Mucous cells are focally and apically immunoreactive for MUC5AC. p40 and CK5/6 clearly decorate the basal cells.

Molecular analysis

We evaluated gene mutations of BRAFV600E, EGFR: exons 18, 19, 20 and 21, ROS1 and ALK-1 rearrangement. Formalin-fixed, paraffin-embedded samples were submitted for Oncomine Dx Target Test. BRAF V600E mutation was demonstrated.

Discussion

BA was first named by Chang and colleagues in 2018 [1]. According to the intrapulmonary location, BA has been subdivided into proximal and distal types, with most cases being the proximal type. Both types microscopically accompany with a two-layered architecture, composed of luminal cells and continuous basal cells [2,3]. The proximal-type BA is also known as ciliated muconodular papillary tumor that Ishikawa reported the first case in 2002, and the luminal cells are composed of ciliated and mucinous columnar cells [4]. The literature review indicated a total of 111 cases of BA or ciliated muconodular papillary tumor reported to date [1-14]. The tumor size ranged from 2 to 65 mm (mean 9.7 mm and median 8.3 mm). BA was often observed in middle-aged and elderly individuals (mean 65.3 years, median 67 years). The youngest case was a 19-year-old girl [3]. BA has occurred in both men and women, with no preference on the location in the lung. Neither recurrence nor distant metastasis was reported during one-month to 10-years post-operative follow-up periods. BA is an indolent tumor with an exceptionally good prognosis, leading some investigators to have a question whether it is a reactive or hamartomatous lesion. The neoplastic nature of BA has been shown by genetic alterations such as BRAF V 600E, EGFR, ALK-1, AKT 1 and KRAS: in the current case, mutation of BRAF V 600E was detected. However, these gene alterations are not specific for BA [1-3,13].

To date, BA may be diagnosed inappropriately as adenocarcinoma during intraoperative consultation, leading to lobectomy rather than local wedge resection. Chang, et al [1] described that for nine cases of BA, intraoperative frozen section diagnoses included adenocarcinoma (n=7) and mucous gland adenoma (n=1). One lesion was appropriately diagnosed. According to Shirsat, et al. [10], only 3 (17%) of 18 were correctly diagnosed intraoperatively, all of which were proximal-type BA: The remainders were diagnosed as adenocarcinoma (n=7); invasive mucinous adenocarcinoma (n=1); non-small cell lung carcinoma (n=1); cystic mucinous neoplasm, favor adenocarcinoma (either mucinous or colloid type) (n=1); favor adenocarcinoma, cannot exclude ciliated muconodular papillary tumor (n=1); atypical proliferation (n=2); mucinous epithelial proliferation (n=1); and mucinous gland adenoma (n=1). Guo, et al. [14] reported an accurate diagnosis of BA in frozen sections. In the current case, the frozen sections revealed continuous lepidic growth of columnar cells resembling adenocarcinoma in situ or lepidic adenocarcinoma. Noteworthy features included a two-layered structure and very bland nuclei of tumor cells without mitotic activities. Richter, et al. [15] described that ultra-rapid immunostaining for p40, p63 or CK 5/6 using frozen sections was extremely helpful for confirming the intraoperative diagnosis of BA.

In the current case, BA of distal type was diagnosed intraoperatively, based upon the same findings as the description by Guo, et al. [14]. We should emphasize that intraoperative cytology was extremely helpful for the accurate diagnosis of BA. In the cytology specimen, ciliated columnal cells, mucous cells, and basal cells without nuclear atypia were identified in the background of mucinous material. Immunocytochemically, p40 was detected in the nuclei of the basal cells.

Conclusion

Despite its rarity, BA should be considered when cytological, histological and immunohistochemical evaluations of a solitary nodule in the peripheral lung reveal non-atypical ciliated, mucous, and basal cells with a mucinous background. To the best of our knowledge, this is the first report that illustrates cytological findings of BA.

Statement of Ethics

All the procedures were in accordance with the ethical standards of the responsible institutional committee on human experimentation and with the Helsinki Declaration of 1964 and later versions. The patient gave a written informed consent to publication as a case report. The study was approved in October 2021 by the Ethics Committee for Clinical Research of Shimada General Medical Center, Shimada, Shizuoka, Japan (approval number 223 R 03-12).

References

1. Chang Jason C, Joseph Montecalvo, Laetitia Borsu, Shaohua Lu and Brandon T Larsen et al. "Bronchiolar Adenoma: Expansion of the Concept of Ciliated Muconodular Papillary Tumors with Proposal for Revised Terminology Based on Morphologic, Immunophenotypic and Genomic Analysis of 25 cases." Am J Surg Pathol42(2018):1010.
2. Chang JC, Beasley MB, Ishikawa Y, Rekhtman N and Yoshida A. “Bronchiolar adenoma/ciliated muconodular papillary tumour.” WHO Classification of Tumours 5th Edition, Thoracic tumours, (2021).
3. Tachibana Mitsuhiro, Masao Saito, Jun Kobayashi, Tadahiro Isono and Yasushi Yatabe, et al. "Distal‐type bronchiolar adenoma of the lung expressing p16INK4a–morphologic, immunohistochemical, ultrastructural and genomic analysis–report of a case and review of the literature." Pathol Int. 70(2020):179-185.
4.  Ishikawa M."Ciliated muconodular papillary tumor of the peripheral lung: benign or malignant." Pathol Clin Med 20(2002):964-965.
5. Ishikawa M."Ciliated muconodular papillary tumor of the peripheral lung: benign or malignant." Pathol Clin Med 20(2002):964-965.
6. Wang B, L Yang, J Lin, Y Wang and SM Wang, et al. "Clinicopathological features of bronchiolar adenoma versus mixed squamous cell and glandular papilloma: a comparative analysis." Chin. J. Pathol. 50(2021): 458-464.
7. Qui Y, Zhang NC, Liu LL, Tan X and Jin N, et al. “Bronchiolar adenoma: a clinicopathological analysis of 12 cases.” Chin. J. Pathol 50(2021):937-39.
8. Shao Jinchen, Jiani C Yin, Hairong Bao, Ruiying Zhao and Yuchen Han, et al. "Morphological, immunohistochemical, and genetic analyses of bronchiolar adenoma and its putative variants." The J Pathol Clin Res 7(2021):287-300.
9. Liu Shuli, Nan Liu, Mingming Xiao, Liang Wang and En-Hua Wang. "First case of bronchiolar adenoma lined purely by mucinous luminal cells with molecular analysis: A case report." Medicine 99(2020).
10. Sun Yajing, Min Liu, Zhongmin Jiang and Baojiang Li. "Bronchiolar adenoma with diffuse pulmonary nodules: a extremely rare case report and review of literature." BMC Pulm Med. 20(2020):1-5.
11. Shirsat Hemlata, Fang Zhou, Jason C Chang, Natasha Rekhtman and Anjali Saqi et al. "Bronchiolar Adenoma/Pulmonary Ciliated Muconodular Papillary Tumor: Potential Pitfall on Frozen Sections." Am J Clin Pathol. 155(2021):832-844.
12. Gao H, XL Du, CN Chen, GX Song and YL Gu, et al. "Bronchiolar adenoma: a clinicopathological analysis of 15 cases." Chin. J. Pathol 49(2020):556-561.
13. Kao Tzu-Hang and Yi-Chen Yeh. "Ciliated muconodular papillary tumor/bronchiolar adenoma of the lung." Semin Diagn Pathol 38(2021):62-71.
14. Yang Chenglin, Xiaoliang Wang, Jiping Da and Kai Ma. "Distal‐type bronchiolar adenoma of the lung harboring an EGFR exon 21 p. L858R mutation: A case report." Thoracic Cancer 11(2020):3596-3598.
15. Guo Yuanyuan, Yanfen Shi and Jie Tong. "Bronchiolar adenoma: a challenging diagnosis based on frozen sections." Pathol Int. 70(2020):186-188.
