Patient 1

A 26-year-old male patient with BMD was referred to our center in 2018 due to a III NYHA class and left ventricular systolic dysfunction. He reported fatigue and lower extremity muscular weakness. Upon clinical evaluation, he presented mild signs of pulmonary congestion and mild hepatomegaly; Arterial Pressure (AP) was 110/65 mmHg and heart rate was 88 bpm. He had normal renal function, potassium and Brain Natriuretic Peptide (BNP) values. He performed 309 m at 6MWT and the FSS was 5. Echocardiography showed a dilated Left Ventricle (LV) (end-diastolic volume (eDV) of 80 mLmq), with 35% of LVEF, mild to moderate Right Ventricle (RV) dysfunction (FAC area 28% and TAPSE 16 mm) and mild mitral regurgitation. His therapy included bisoprolol 2.5 mg, valsartan 60 mg, furosemide 25 mg. considering all data; we decided to stop valsartan and furosemide and to introduce S/V 24/26 bis in die (bid). Four weeks later, the patient reported a significant clinical improvement, with an II NYHA class, a FSS of 4 and 341 meters at 6MWT; echo and lab parameters were almost stable, therefore S/V was increased to 49/51 mg bid. Three months later a CMR showed a mild biventricular improvement: a moderate LV systolic dysfunction (38%) in a diffuse hypokinetic LV, with a thin intramyocardial Late Gadolinium Enhancement (LGE) at intraventricular septum and a mild RV dysfunction (40%).

A slow-but complete-up-titration of S/V to 97/103 mg bid was completed over 4 months. NYHA class improved to I, volume remodelling was accomplished (eDV of 67 mL/mq) and LVEF stabilized at 40%. Six months later, this clinic improvement was confirmed at 6MWT, with 355 m covered, and at the cardiopulmonary test, with a peak VO2 of 18.4 mL/min/kg. Bisoprolol therapy was increased to 3.75 mg daily. At the one-year follow-up, all positive clinical features were confirmed (NYHA I, FSS 3 and 369 m at 6MWT) and a CMR showed a further improvement, with mild to moderate LV dysfunction (LVEF 43%) and normalization of the RV function (RVEF 55%). The patient completed a two-year follow-up, showing clinical and echocardiographic stability. The introduction of S/V was safe and associated with a progressive clinical improvement that it is crucial, considering the case of a young patient already limited in his daily life by muscular weakness. Moreover, thanks to therapy optimization in an early phase of dilated CMP, we witnessed an inverse LV and RV remodelling and a biventricular function improvement. The increase in systolic function allowed delaying the indication for a primary prevention implantation of an Implantable Cardioverter Defibrillator (ICD).

Patient 2

In 2015, a 21-years-old male patient with BMD was found to have a moderate left ventricular dysfunction. One year later, CMR examination reported a dilated LV with a moderate systolic dysfunction (LVEF 42%) and an extended epicardial-subepicardial LGE at the infero-lateral wall and apex. Because of a reported hypotension, therapy with a low dose ramipril (1.25 mg center in 2019, when he presented an I NYHA class, a LVEF of 45%, an heart rate of 65 bpm and normal lab values. Despite baseline values of blood pressure (AP=100/65 mmHg), he was encouraged to increase ramipril to 2.5 mg daily. In 2020, at his routine annual visit: NYHA class was I, his fatigue perception at FSS was 1.3 and, the blood pressure was stable (AP=105/80 mmHg). He had a good performance at 6MWT, with 468 m covered. However, a mildly dilated (eDV 78 mL/mq) and hypokinetic LV with EF of 35-38% and a Global Longitudinal Strain (GLS) of -15% was found. Mitral regurgitation was mild. We stopped ramipril and started S/V 24/26 mg bid.

Thirty days after the introduction of S/V, the patient referred stable clinical condition; moreover, despite a low basal blood pressure, the drug was well tolerated. Three months later, CMR showed an improved LVEF of 44% with unmodified epicardial-subepicardial LGE at the inferolateral wall and apex (Figure 1). The RV appeared mildly dilated, with normal pump function. The dose was not changed, due to AP values of 105/70 mmHg. At 6 months follow-up visit all clinical, functional and laboratoristic parameters were stable. The echocardiographic evaluation confirmed a mild inverse remodelling (LVeDV 72 mL/mq) with moderate LV dysfunction (LVEF 42%) and normal RV performance. In this case, S/V was used in order to obtain a substantial positive effect on inverse LV remodelling and pump function, considering the young age of the patient. The LVEF improvement allowed, also in this case, delaying the need of ICD implantation.

Figure 1. Images of cardiac magnetic resonance belonging to patient 2 and showing late gadolinium enhancement at inferolateral wall and apex in a four-chamber (a) and in a short-axis view (b).

Patient 3

In 2016, a 61-years-old man with BMD and severe muscular involvement was implanted for paroxysmal III degree atrioventricular block. At that time, he presented mild left ventricular dysfunction (LVEF 50%). In 2018 he complained dyspnoea on mild exertion (NYHA III) with a FSS of 4.7; at echo, LVEF was 30% with mild RV impairment. The rate of ventricular pacing was 15%. Renal function was normal and BNP value 226 pg/ml. The patient was assuming furosemide 25 mg, spironolactone 50 mg, olmesartan 20 mg and amlodipine 5 mg. The antihypertensive drugs were stopped and S/V 49/51 mg bid was introduced. Three months later, LVEF was 45%, NYHA changed from III to II and FSS was 3.3. These values remained stable since his last evaluation, at 2-years follow up. This case report shows the safe use of S/V in an older patient with severe functional limitation due to muscular dystrophy. It also confirms the significant clinical and echocardiographic improvement related to S/V, when introduced early, as soon as the dysfunction is identified.

Patient 4

In 2016, a 56-years-old patient with BMD was diagnosed with a dilated cardiomyopathy complicated by severe LV systolic dysfunction; in the same year he underwent to ICD implantation for primary prevention. The patient had a severe functional limitation due to dyspnoea and muscular impairment. In 2017 and 2018 he was also hospitalized for episodes of worsening HF, requiring IV diuretics. In 2019 the patient came to our attention. He was a III NYHA class, with a FSS of 4.6. Blood pressure was 140/90 mmHg and his therapy included bisoprolol 3.75 mg, ramipril 5 mg, furosemide 25 mg, spironolactone 25 mg. Upon the echocardiographic evaluation, he presented a dilated (eDV 93 mL/mq) and severely impaired (EF 32%) LV with a normocinetic RV. Mild to moderate mitral regurgitation was also present. Renal function was normal. He had moderate-severe legs muscle weakness, hyperlordosis, waddling gait. We introduced S/V 49/51 mg bid and we suspended furosemide. The patient soon reported a clinical improvement, with an II NYHA class and a FSS of 3.8, regular blood pressure values and normal lab parameters at a 6-month evaluation. S/V was up-titrated to maximal dosage. One year later, clinical conditions were stable with II NYHA class and no hospital admissions for HF. Left ventricular systolic function was unchanged, while mitral regurgitation was mild. The patient reported a further clinical improvement in functional capacity. These data were all confirmed at the 18-month follow-up evaluation. In this case, S/V was used at later stage of BMD cardiomyopathy when the objective was to improve the clinical status and reduce hospital admissions for heart failure worsening, with an evident gain in quality of life.

Discussion

Becker Muscular Dystrophy is related to dystrophin mutations resulting in an abnormal and less functional protein. Compared to Duchenne Muscular Dystrophy (DMD) patients in whom dystrophin is totally absent and muscular involvement is severe and has an early onset, BMD patient’s typically present late- and often not limiting- muscular weakness [1]. Cardiomyopathy in BMD is more frequent and severe compared to Duchenne and may precede skeletal muscle decline. Cardiomyopathy with refractory HF is the leading cause of death in BMD. Becker patients with cardiomyopathy usually received the accepted standard HF therapy. Systematic review and metanalysis have shown that Angiotensin Converting Enzyme Inhibitors (ACE-I), angiotensin receptor blockers, Beta-Blockers (BB) and/or aldosterone antagonists tend to improve or preserve left ventricular systolic function and delay the progression of dystrophinopathic cardiomyopathy [15,16]. In symptomatic Class IV HF, symptoms and LVEF improve transiently when ACE-I and BB therapy are initiated. However, the certainty of the evidence is very low due to the paucity of trials, the small numbers of participants studied and the lack of hard endpoint as survival. Therefore, cardiac management remains highly variable and, generally, underused [2-5].

Over the last years, S/V has been found to improve both survival and quality of life and to reduce hospitalisation when compared to an ACEinhibitor in patients with chronic HF and reduced LVEF [7], which resulted in its introduction in HF treatment guidelines [6]. Little is known about the use of S/V for HF in dystrophic patients. The main findings of S/V use in our four BMD cases analysis series are related to the following main aspects. First, our experience shows the safety of S/V in this fragile population; no clinical significant hypotension, nor any renal failure were described. Probably, the absence of adverse events was also favoured by a slow up-titration of the drug, when feasible, which allowed patients to progressively get used to the hemodynamic effects of S/V. Secondly, we noted the effects of S/V in cardiac reverse remodeling and in gain in pump function when the drug is used in an early phase of dilated cardiomyopathy, especially in young BMD patients, as it was previously demonstrated in the general HF population [17-19]. Sacubitril/ valsartan has been shown to reduce profibrotic signalling in HF with reduced ejection fraction, which may contribute to the improved outcomes in treated patients [20]. Becker cardiomyopathy pathology includes the development of subepicardial fibrosis in the inferolateral wall first, and, then, its progressive diffusion.

Myocardial fibrosis correlates with LVEF decline: an early recognition of cardiac involvement and treatment with S/V of BMD patients may slow this process and the progress towards refractory HF. The use of S/V in a larger cohort of BMD patients would be desirable to confirm these potential effects. Moreover, the early introduction of S/V, by promoting a significant improvement in ventricular function, may delay the indication of ICD implantation for primary prevention. Lastly, S/V use was associated with a significant improvement in term of functional capacity, and dyspnoea. This population is already fatigued, due to a long history of limbs and respiratory muscular weakness. Thus, in these patients it is worthy of remark the effect of S/V in reducing HF symptoms that usually aggravate the neuromuscular involvement, further limiting daily activities and quality of life. In our population of BMD patients, BNP was a less sensitive biomarker in detecting severe cardiomyopathy, as previously reported [21,22]. Low values were detected at baselines evaluation, despite severe left ventricular dysfunction, and, moreover, along the follow-up the variation of BNP after S/V introduction was not significant. Further studies are needed to explain the precise mechanism of this finding.

We compared our data with literature findings. We only found a study by Papa et al., who treated a single BMD patient with S/V [10]. The patient presented very rapid clinical and echocardiographic improvements only 30 days later. In our experience clinical and echocardiographic improvements were already evident in the first months of drug administration, also at low doses, and benefits progressively increased over time, and with the titration of the therapy. No further data are available on the use of S/V in BMD patients. However, considering the common etiology of Becker and Duchenne dystrophy and the similar cardiac involvement, our data are aligned with the experience of Lamendola et al., who administered S/V to three young asymptomatic Duchenne patients, with significant improvement of LV function and remodeling [9]. Moreover, we present data resulting from a longer follow-up than the ones reported by other authors [9,10]. In our case series, the use of S/V is safe: all patients did not present symptomatic or asymptomatic hypotension or arrhythmic complications, as previously reported in a Duchenne patient [11].

Conclusion

Our experience suggests that S/V may be considered an effective and safe pharmacological option in patients with BMD and dilated cardiomyopathy with reduced ejection fraction, since it could promote symptoms control and functional improvement, as well as -when early introduced- an increase in LV and RV function and positive reverse heart remodeling.

References

1. Emery, Alan. “The Muscular Dystrophies.” Lancet 359 (2002): 687-695.
2. Forum Kamdar and Daniel J. Garry. “Dystrophin-Deficient Cardiomyopathy.” JACC 67 (2016): 2533-2546.
3. David J. Birnkrant, Katharine Bushby, Carla M Bann and Benjamin A Alman, et al. “Diagnosis and Management of Duchenne Muscular Dystrophy, Part 2: Respiratory, Cardiac, Bone Health, and Orthopaedic Management.” Lancet Neurol 17 (2018): 347-361.
4. Brian Feingold, William T. Mahle, Scott Auerbach and Paula Clemens, et al. “Management of Cardiac Involvement Associated with Neuromuscular Diseases: A Scientific Statement from the American Heart Association.” Circul 136 (2017): 200-231.
5. Eloisa Arbustini, Alessandro Di Toro, Lorenzo Giuliani and Valentina Favalli, et al. “Cardiac Phenotypes in Hereditary Muscle Disorders: JACC State-of-the-Art Review.” JACC 72 (2018): 2485-2506.
6. Piotr Ponikowski, Adriaan A. Voors, Stefan D. Anker and Héctor Bueno, et al. “2016 ESC Guidelines for the Diagnosis and Treatment of Acute and Chronic Heart Failure.” Eur Heart J 37 (2016): 2129-2200.
7. John J.V. McMurray, Milton Packer, Akshay S. Desai and Jianjian Gong, et al. “For the PARADIGM-HF Investigators and Committees: Angiotensin-Neprilysin Inhibition versus Enalapril in Heart Failure John.” N Engl J Med 371 (2014): 993-1004.
8. Sashiananthan Ganesananthan, Nisar Shah, Parin Shah and Hossam Elsayed, et al. “Real-World Treatment Switching to Sacubitril/Valsartan in Patients with Heart Failure with Reduced Ejection Fraction: A Cohort Study.” Open Heart 7 (2020): 1305.
9. Angelo Villano, Erica Mencarelli, Veronica Melita and Alessandro Rizzi, et al. “Duchenne Muscular Dystrophy: Preliminary Experience with Sacubitril-Valsartan in Patients with Asymptomatic Left Ventricular Dysfunction.” Euro Rev Med Pharmacol Sci 24 (2020): 9112-9115.
10. Andrea Antonio Papa, Paola D'Ambrosio, Roberta Petillo and Alberto Palladino, et al. “Beneficial Effects of One-Month Sacubitril/Valsartan Treatment in a Patient Affected by End-Stage Dystrophinopathic Cardiomyopathy.” Acta Myol 39 (2020): 136-140.
11. Jia-Min Li and Han Chen. “Recurrent Hypotension Induced by Sacubitril/Valsartan in Cardiomyopathy Secondary to Duchenne Muscular Dystrophy: A Case Report.” World J Clin Case 7 (2019): 4098-4105.
12. Sherra Solway, Dina Brooks, Yves Lacasse and Scott Thomas. “A Qualitative Systematic Overview of the Measurement Properties of Functional Walk Tests Used in the Cardiorespiratory Domain.” Chest 119 (2001): 256-270.
13. Ivone M. Ferreira, Dina Brooks, Yves Lacasse and Roger S. Goldstein. " Nutritional Intervention in COPD.” Chest 119 (2001): 353-363.
14. Krupp, Lauren. “The Fatigue Severity Scale: Application to Patients with Multiple Sclerosis and Systemic Lupus Erythematosus.” Arch Neurol 46 (1989): 1121-1123.
15. John P Bourke, Teofila Bueser and Rosaline Quinlivan. “Interventions for Preventing and Treating Cardiac Complications in Duchenne and Becker Muscular Dystrophy and X-Linked Dilated Cardiomyopathy.” Cochrane Database Syst Rev 10 (2018): 9068.
16. Jasmine Kipke, David J. Birnkrant, Justin B. Jin and Ashish Aneja, et al. “A Systematic Review of Pharmacologic Therapies for the Cardiomyopathy of Duchenne Muscular Dystrophy.” Pediatr Pulmonol 56 (2021): 782-795.
17. Pieter Martens, Hanne Beliën, Matthias Dupont and Pieter Vandervoort, et al. “The Reverse Remodeling Response to Sacubitril/Valsartan Therapy in Heart Failure with Reduced Ejection Fraction.” Cardiovasc Ther 36 (2018): 12435.
18. Carlos de Diego, Luis González-Torres, José María Núñez and Raúl Centurión Inda, et al. “Angiotensin-Neprilysin Inhibition Further Reverses Cardiac Remodeling as Compared to Angiotensin Inhibition in Reduced Heart Failure Patients.” Euro 20 (2018): 139.
19. Yiwen Wang, Ran Zhou, Chi Lu and Qing Chen, et al. “Effects of the Angiotensin- Receptor Neprilysin Inhibitor on Cardiac Reverse Remodeling: Meta-Analysis.” J Am Heart Assoc 8 (2019): 12272.
20. Michael R. Zile, Eileen O'Meara, Brian Claggett and Margaret F. Prescott, et al. “Effects of Sacubitril/Valsartan on Biomarkers of Extracellular Matrix Regulation in Patients with HFrEF.” J Am Coll Cardiol 73 (2019): 795-806.
21. Jun Demachi, Yutaka Kagaya, Jun Watanabe and Masahito Sakuma, et al. “Characteristics of the Increase in Plasma Brain Natriuretic Peptide Level in Left Ventricular Systolic Dysfunction, Associated with Muscular Dystrophy in Comparison with Idiopathic Dilated Cardiomyopathy.” Neuro Disorders 14 (2004): 732-739.
22. Steven Schade van Westrum, Lukas Dekker, Rob de Haan and Erik Endert, et al. “Brain Natriuretic Peptide is Not Predictive of Dilated Cardiomyopathy in Becker and Duchenne Muscular Dystrophy Patients and Carriers.” BMC Neurol 13 (2013): 88.
